제품명

SW-D04

비츠로셀의 리튬일차전지는 스마트미터 시장에서 널리 쓰이며 현재 50개국 이상에 제품을 수출하고 있습니다.
문의사항

주요특징

  • High and stable operating voltage
  • Low self-discharge rate
  • (inferior to 1% yearly, when keeping at room temperature of 20°C)
  • Non-flammable inorganic electrolyte
  • Excellent pulse property
  • GTM (Glass-to-Metal) hermetic structure
  • Wound type (safe vent applied)
  • UL Certification (File Number MH18384)
  • RoHS

외형치수

사양


Nominal voltage

3.6V

Nominal capacity

(at 20mA, 20℃, 2.0V cut off)

14.0Ah

Maximum recommended continuous current

(Higher currents are possible, consult Vitzrocell)

1,800mA

Maximum pulse discharge current

3,000mA

Weight

max. 102.0g

Operating temperature range

-55~85℃

참고사항

Available Terminals : TC ST 2P 3P 3PW AX Other type available by reques

Max. pulse current/0.1 second pulses, drained every 2 min at + 20 °C from undischarged cells with 10 μA base current, yield voltage readings above 3.0V. The readings may vary according to the pulse characteristics, the temperature, and the cell's previous history. Fitting the cell with a capacitor may be recommended in severe conditions. Consult Vitzrocell.
